218|V - Link-Belt Cranes

218|V

Base Rating	110 USt @ 11 ft 100 mt @ 3.4 m
Boom Lengths	40 ft – 230 ft 12.2 m – 70.1 m
Fixed Jib Lengths	30 ft – 75 ft 9.1 m – 22.9 m
Fixed Jib Offsets	5°, 15°, & 25° 5°, 15°, & 25°
Maximum Combination (Fixed Jib)	Tube: 200 ft + 75 ft Tube: 61 m + 22.9 m
Maximum Tip Height (Fixed Jib)	278.6 ft 84.9 m
Engine Make & Model	Cummins QSB6.7 Tier 4 Final/Stage V Cummins QSB6.7 Tier 4 Final/Stage V
Maximum Hoist Line Pull / Speed	44,565 lbs / 583 fpm 20 214 kg / 177.7 mpm
Working Weight	204,470 lbs 92 746 kg
Main Transport Load	99,960 lbs w/ tracks 45 341 kg w/ tracks

View Larger

Brochure

Technical Data

All Cranes Lattice Crawler Cranes

Key Features

Spacious, air-conditioned cab featuring wide job site views
Fully adjustable seat and console for operator comfort
NEW HSL-2 10-inch touch screen load moment limiter with continuous display of list and trim angles and ground bearing pressures
Cummins engine, compatible with HVO fuel
Operator-settable working range restrictions with function slow down/stop
Link-Belt’s Vision Package standard with rear, winch, and swing cameras
Dual throttle for engine speed and pump flow
Designed for multifunction under any load condition
Standard auto brake and free swing functions
Standard Winch Package with wet brakes and free fall
Standard ECO winch for faster line speeds with lower engine RPM
Full self-assembly – No assist crane required
Heavy-duty undercarriage designed for durability and longevity
Pick and carry all 360° capacities on level ground
iCraneTrax telematics equipped
Wire rope pendants store on top of boom sections
All boom sections feature double-tapered connection pins with pin catcher storage brackets
All overflow loads transport under 45,000 pounds (20 411 kilograms)

Media

Frequently Asked Questions

Can the 218|V be configured with a power pack for foundation applications?GRIFFIN FLETCHER2026-10-07T10:27:36-05:00

Can the 218|V be configured with a power pack for foundation applications?

Yes, Link-Belt lattice cranes can accommodate a customer-designed power pack frame that is mounted to the rear of the upper crane for foundation-work. The 218|V is uniquely suited for this application, as it comes with designated mounting lugs that help simplify the frame design and installation process. Please contact your nearest Link-Belt Cranes distributor to begin the approval process.

What are the new advancements on the 218|V?GRIFFIN FLETCHER2026-10-07T10:32:27-05:00

What are the new advancements on the 218|V?

The 218|V incorporates several enhancements from Link-Belt’s V Series platform, including the 12-inch HSL-2 Load Moment Limiter display, LED lighting package, Cummins Stage V engine, Auxiliary Power Unit, improved side frame extension and retraction, power pack mounting lugs, enhanced self-assembly and disassembly procedures, fall-protection anchor points, screw-type quick disconnects, and button-style sockets for the load hoist drums. These updates improve operator experience, serviceability, and overall job site efficiency.

What models offer an Auxiliary Power Unit (APU), and how can it reduce operating costs?GRIFFIN FLETCHER2026-10-12T09:11:57-05:00

What models offer an Auxiliary Power Unit (APU), and how can it reduce operating costs?

The 218|V, 228 HSL, and 248|V have a Link-Belt-designed APU that allows the main unit’s engine to be off while continuing to power the cab, LML display, Bluetooth radio, heated seat, and all lights while providing climate control. This greatly reduces fuel consumption and engine hours on the main engine. The APU is also available as a retrofit kit for existing 218|V, 218 HSL, 228 HSL, and 248|V cranes.
